Quick Haul D8: Budget Compact E-Cargo Bike
What Makes it a D8?
- Bosch Active Line Plus motor provides up to 50 Nm of torque and 270% support
- 1x8-speed Shimano Altus groupset with trigger shifter
Quick Haul Highlights
- Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack
- Fits riders 160 - 195 cm (5’3” - 6’5”), and also riders 145 - 180 cm (4’9” - 5'11") when equipped with a shorter, 350 mm seatpost
- Lots of available kid- and cargo-carrying accessories—easily create your perfect setup
- Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
- Shimano hydraulic disc brakes for reliable stopping power—even when heavily loaded and riding fast
- Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
Gallery
Click any image for full size · hover to pause
Specifications
General Info
- Generation
- Gen 1
- Color(s)
- Quick Haul - Blue Grey, Quick Haul - Tabasco
- Speeds
- 1 x 8
- Weight
- 22.8 kg (50.3 lb)
- Gear Inches
- 31" - 95" (2.45 - 7.57 m)
- Frame Sizes
- One size
- Bike Size
- 172.5 × 70 × 102.5 cm (67.9 × 27.6 × 40.4 in)
- Distance: Seatpost to Handlebar
- 60 - 64 cm (23.6 - 25.2 in)
- Distance: Saddle to Pedal
- 68 - 110 cm (26.8 - 43.3 in)
- Suggested Rider Height
- 160 - 195 cm (63 - 76.8 in)
- Max Gross Vehicle Weight
- 150 kg (330.7 lb)
- Max Rider Weight
- 120 kg (264.6 lb)
Frame
- Frame
- Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg
- Fork
- Cargo, steel, EFBE approved: 150 kg
Cockpit
- Stem
- Speedlifter, 150 mm extension, 3D Forged stem, 31.8
- Headset
- TH, cartridge bearings
- Handlebar
- Low riser, 31.8, 6061-AL
- Grips/Bar Tape
- Velo ergonomic, lock-on
- Saddle
- Velo Comfort
- Seatpost
- 31.6 mm, 6061-AL, micro-adjust clamp
- Seatpost Clamp
- Tern Collar
Brakes
- Front Brake
- Shimano, hydraulic disc
- Rear Brake
- Shimano, hydraulic disc
- Brake Levers
- Shimano, hydraulic disc
- Brake Cable & Housing
- Shimano, hydraulic disc
Wheels
- Front Hub
- Shimano disc
- Rear Hub
- Shimano disc
- Spokes & Nipples
- Stainless steel
- Rims
- Kinetix Comp, for disc
- Tyres
- Schwalbe Big Apple, 55-406, puncture protection, Reflex
Transmission
- Shifter
- Shimano Altus, 1 x 8 spd, trigger
- Rear Derailleur
- Shimano Altus Shadow
- Crankset
- Tern custom, forged 6061-AL crankarm
- Cassette/Freewheel
- Shimano 11-34T, 8 spd
- Bottom Bracket
- Motor integrated
- Chain
- KMC for eBike, 8 spd
- Pedals
- Urban with non-slip surface
- Shifter Cable & Housing
- SP
E-System
- Motor
- Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
- Battery
- Bosch PowerPack 400
- Display
- Bosch Purion
- Range
- 400 Wh: 54 - 105 km (33.6 - 65.2 mi)
- Charger
- Compact Charger, 100-240V, 2A
Bells & Whistles
- Bell
- Aluminum
- Chainguard
- SKS Chainblade
- Kickstand
- Pletscher design, rear mount
- Luggage Socket
- Combo Mount
- Front Light
- Herrmans, 120 lumens
- Rear Light
- Herrmans
- Fenders
- Chromeplastic, stainless hardware
- Rack
- Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity
Please note: These are the manufacturer’s standard specifications for this model. Quoted weight and folded dimensions may not include racks, mudguards or other accessories. Specification for UK-supplied bikes can differ slightly from other markets. We do our best to keep the details here accurate, but Tern may change components from time to time and updates on this page can lag briefly. Component changes may be made without prior notice, so the bike you receive may differ in small ways from the information listed here.
